APC Symmetra LX 12kVA UPS

Name: APC Symmetra LX 12kVA UPS
Brand: APC
SKU: a0452187

High performance, redundant power protection with scalable power and runtime for space-constrained server rooms, and voice and data networks.

CAD $27,452.99

Add to Cart

Manufacturer part SYA12K16P | Dell part A0452187 | Order Code a0452187 | American Power Conversion

Compare Compare

High performance, redundant power protection with scalable power and runtime for space-constrained server rooms, and voice and data networks.

Shop Similar Products

Tech Specs

Technical Information

Plug/Connector Type

Hard Wire 4-wire

Receptacle Type

Hard Wire 4-wire (2PH+N+G)

Receptacle Detail

1 x Hard Wire 4-wire (2PH+N+G)

Number of Battery & Surge Outlets

Overload Protection

Yes

Power Description

Load Capacity (VA)

12 kVA

Input Voltage

208 V AC

Output Voltage

120 V AC
208 V AC

Input Frequency

65 Hz

Output Frequency

60 Hz

Input Current

56 A

Waveform Type

Sine Wave

Management

Network Management

SNMP Manageable

Bypass Switch

Automatic & Manual

Emergency Power OFF

Yes

Interfaces/Ports

Modular Slots

1 x SmartSlot

Battery Information

Battery Characteristics

Spill-proof/Maintenance-free

Battery Chemistry

Lead Acid

Backup/Run Time (Full Load)

6 Minute

Backup/Run Time (Half Load)

17.10 Minute

Typical Battery Recharge Time

3 Hour

Environmental Conditions

Maximum Operating Temperature

104^°F (40^°C)

Thermal Dissipation

4995 BTU/h

Physical Characteristics

Color Family

Dual Color

Product Color

Black
Silver

Form Factor

Tower

Mounting Location

Front

Height

36.89" (937 mm)

Width

19.02" (483 mm)

Depth

28.58" (726 mm)

Weight (Approximate)

581.23 lb (263641.49 g)

Mounting Preference

No Preference

Miscellaneous

Package Contents

Symmetra LX 12kVA UPS

CD with software

Installation guide

User manual

Web/SNMP management card

Additional Information

Audible and visible alarms prioritized by severity
Configurable for 120/208 or 120/240 output voltage
Configurable for N+1 internal redundancy
Redundant Intelligence Modules
Hot-swappable intelligence modules
Hot-swappable power modules
Automatic restart of loads after UPS shutdown
InfraStruXure Manager Compatible
Removable input/output wiring tray
Cold-start capable
Generator Compatible

Certifications & Standards

CSA

Green Premium

Yes

Optimized Energy Efficiency

Yes

Product Take Back Program

Yes

California Proposition 65 Warning

WARNING: This product can expose you to chemicals including: Lead and lead compounds, which is known to the State of California to cause cancer and birth defects or other reproductive harm. For more information go to www.P65Warnings.ca.gov

REACH free of SVHC

Country of Origin

United States

Environmentally Friendly

Yes

Environmental Compliance

Restriction of Hazardous Substances (RoHS)

For Country/Region

United States

Warranty

Limited Warranty

2 Year

Additional Warranty Information

2 years repair or replace

General Information

Manufacturer

Schneider Electric SA

Manufacturer Part Number

SYA12K16P

Brand Name

APC by Schneider Electric

Product Line

Symmetra

Product Series

Product Name

Symmetra LX 12kVA UPS

Product Type

Double Conversion Online UPS

Marketing Information

High performance, redundant power protection with scalable power and runtime for space-constrained server rooms, and voice and data networks.
