CAD $99.99
Manufacturer part U444-T6N-VUBC | Dell part AB371362 | Order Code ab371362 | TrippLite
.png)
Transform Your Laptop’s USB-C Port into a Multiport Workstation Wherever You Go
Newer tablets, laptops, Chromebook™ and MacBook® notebooks, desktop computers and even smartphones often have only USB Type-C™ ports for connection to peripherals. This Tripp Lite docking station expands the functionality of the USB-C™ or Thunderbolt™ 3 port on your device and makes it compatible with existing equipment.Typical Applications
- Send video to a VGA monitor.
- Add a USB-A peripheral to your computer.
- Power and charge your laptop.
- Convert your Chromebook or MacBook into a powerful and portable workstation.
.png)
Simplify Travel with an All-In-One USB-C Docking Station
One USB-C connection provides different ports, so you don’t need multiple adapters. This docking station is also bus-powered, so you don’t need an external power supply. If you keep the docking station on your desk, you will have only one cable to unplug when you take your laptop on the road.
- With a footprint similar in size to a credit card, this portable docking station fits almost anywhere.
- Lightweight, streamlined design doesn’t add weight to your load.
- Built-in cable wraps around the docking station when not in use.
- Plug-and-play operation means you don’t need software or drivers.
.png)
Display High-Definition Video on a VGA Monitor
This docking station supports DisplayPort Alternate Mode (Alt Mode) for carrying high-definition video to a VGA monitor or projector. It supports video resolutions up to 1920 x 1200 at 60 Hz, including 1080p.- Show the same video on your laptop and a second monitor.
- Use a second monitor as your primary screen.
- Extend video to a second monitor.
- Share video in a conference room, classroom or auditorium setting.
.png)
Connect a USB Peripheral
A USB-A port provides a place to connect a USB peripheral, like a flash drive or a USB mouse. Or, you can connect a printer with a USB cable when a wireless connection isn’t feasible. The docking station supports USB 3.1 Gen 1 data transfer speeds up to 5 Gbps. It is backward compatible with previous USB generations. The USB-A port provides up to 1.5A for charging devices..png)
Keep Ports Available While Your Laptop Charges
Limited USB-C ports can force you to choose between connecting a peripheral and charging your laptop’s battery. The USB-C Power Delivery (PD) port powers and charges your laptop without affecting the other connections. Your laptop’s wall charger connects to the USB-C PD port, which supports power input up to 20V, 5A (100W). The USB-C port also supports data transfer.
Media
.png)
.png)
.png)
.png)
.png)
.png)
.png)
.png)
.png)
.png)
Thunderbolt™ is a trademark of Intel Corporation or its subsidiaries in the U.S. and/or other countries. USB Type-C™ and USB-C™ are trademarks of USB Implementers Forum. All other trademarks are the property of their respective owners. Tripp Lite has a policy of continuous improvement. Specifications are subject to change without notice. Images may differ slightly from actual products. Tripp Lite uses primary and third-party agencies to test products for compliance with standards. Go to Tripp Lite's website for more information, including complete warranty terms and conditions.
This USB 3.1 C adapter helps you transmit 1080p video from your tablet, laptop, Chromebook, MacBook, smartphone or PC to a VGA-enabled television, monitor or projector. It's an ideal tool for giving video presentations in conference rooms and classrooms, editing multiple documents on a larger screen, or streaming video for digital signage in crystal-clear 1080p.
By connecting the self-storing USB-C cable to a source device that supports USB DisplayPort Alt Mode, you can output video to a compatible monitor, television or projector without installing special software drivers.
To send high-definition video to a VGA television, projector or monitor, connect the VGA port to the display using a VGA cable (such as Tripp Lite's P502-Series VGA cables, sold separately). The USB to VGA adapter supports video resolutions up to 1920 x 1200 (1080p) at 60 Hz.
The USB-A 3.0 port accepts USB peripherals, such as a flash drive, mouse, keyboard or printer, and provides up to 1.5 amps (7.5 watts) for charging and powering mobile devices. Like the USB-C port, it transfers data at speeds up to 5 Gbps, which is 10 times faster than USB 2.0. The USB Type-C adapter is backward compatible with previous USB generations, so you can continue using older peripherals while getting high-speed performance from new devices.
The USB-C Power Delivery 3.0 port provides power output up to 5 amps (100 watts), which is more than sufficient for charging and powering the connected source device, such as a MacBook or Chromebook. Just connect the device's AC wall charger to the USB-C PD port and enjoy fast USB 3.1 Gen 1 data transfer speeds up to 5 Gbps. Like the USB-A port, it is backward compatible with previous USB generations.
Connect the reversible USB-C plug to your source device's USB-C or Thunderbolt 3 port. The fumble-free USB-C plug connects in either direction to ensure fast, easy connection every time. The six-inch cable wraps into the adapter when not in use, making the unit easy to carry in a briefcase or laptop bag for connecting on the go.
The plug-and-play USB 3.1 Type-C adapter is specifically designed for the MacBook, Google Chromebook Pixel and other laptops, tablets and devices equipped with a USB-C or Thunderbolt 3 port. It requires no software, drivers or external power.
Tech Specs
General
Product Type
Docking stationEnclosure Colour
BlackVideo
Max Resolution Details
1920 x 1200 - 60 HzExpansion / Connectivity
Interfaces
- 1 x SuperSpeed USB 3.0 - 9 pin USB Type A
- 1 x video - VGA output - 15 pin HD D-Sub (HD-15)
- 1 x USB-C with Power Delivery - 24 pin USB-C
Miscellaneous
Cables Included
1 x USB-C cable - integrated - 15.2 cmFeatures
Nickel plated, bus powered, reversible USB-C plug connectsCompliant Standards
Plug and Play, FCC, RoHS, VW-1Manufacturer Warranty
Service & Support
Limited warranty - 3 yearsEnvironmental Parameters
Min Operating Temperature
0 °CMax Operating Temperature
45 °C
