5kVA SmartOnline On-Line Double-Conversion UPS

Name: 5kVA SmartOnline On-Line Double-Conversion UPS
Brand: Tripplite
SKU: a4210662
Rating: 3.5 (2 reviews)

3.5 (2) Ask a Question

$3,939.08

Temporarily Out of Stock

Financing Offers Learn More

Manufacturer part SU5000RT4UHV | Dell part A4210662 | Order Code a4210662 | TrippLite

Compare Compare

SU5000RT4UHV SmartOnline® Double-Conversion Rack/Tower Sine Wave UPS with Expandable Runtime, Network Slot and LCD/LED Control Panel

POWER PROTECTION AND BATTERY BACKUP
for servers and network hardware

This on-line, double-conversion UPS system protects critical network systems from damage, downtime and data loss.

True on-line, double-conversion operation delivers pure sine wave output, precise voltage regulation and isolation from power problems.
LCD/LED control panel displays power conditions and permits easy access to settings.
Expandable battery backup powers critical systems during outages.
Hot-swappable battery modules support the continuous availability of critical systems connected to the UPS.
Network card slot supports optional remote access and network management.
USB and DB9 serial ports connect to computers for power management.
2-year warranty and $250,000 insurance reflect commitment to reliability.

SU5000RT4UHV SmartOnline® Double-Conversion Rack/Tower Sine Wave UPS with Expandable Runtime, Network Slot and LCD/LED Control Panel

Media

slide {0} of {1}, zoom in, SU5000RT4UHV SmartOnline® Double-Conversion Rack/Tower Sine Wave UPS with Expandable Runtime, Network Slot and LCD/LED Control Panel

4:06

Why is this UPS a Good Investment?

The success of your organization depends on critical information systems like servers and network hardware. If your critical systems don't have reliable power, employees can't work, communications go down, automated systems malfunction and productivity grinds to a halt. It would be nice if utility power was always reliable, but it isn't. Between severe weather, the aging electrical grid and hazards lurking inside your own walls, your servers and network hardware are under attack from power problems. Even a brief loss of power or a momentary surge can damage your equipment, corrupt your data, bring down your network and hurt your bottom line.

The potential costs of downtime are alarming. Surveyed averages range from $1,167 per minute for mid-size businesses (IDC) to $7,908 per minute for larger operations (Ponemon Institute). For a tiny fraction of these costs, you can prevent damage, downtime and data loss by installing this SmartOnline UPS system. True on-line double conversion is the highest level of power protection available. It provides precise voltage regulation, delivers continuous sine wave output and isolates equipment from power problems. This UPS system also has a high power factor, allowing you to connect a heavier load without overloading the UPS.

Common Applications

Protect Mission-Critical Servers and Network Hardware
Application Servers, Storage Servers, Database Servers, File Servers, Virtualization Servers, Proxy Servers, Web Servers, Cloud Platform Servers, Media Servers, VoIP Servers, Converged Infrastructure, Network Switches, PoE Switches, Firewalls, Network Appliances, Bridges, Gateways, Routers Protect Equipment with Active PFC Power Supplies
Active PFC power supplies found in many devices require sine wave power.

Expandable Battery Backup

Half-Load Runtime: This UPS system will support a 50% load (2250W) for up to 11 minutes using the included batteries.
Extended Runtime: This UPS system allows you to connect one or more optional external battery packs to provide additional backup runtime. Some external battery packs can also be daisy-chained, allowing you to scale runtime to match almost any application requirement.
Hot-Swappable Batteries: You can add or replace batteries without turning off the UPS system and disrupting the operation of connected equipment.

On-Line, Double-Conversion Operation

This UPS system provides the highest level of power protection available:

Continuous on-line, double-conversion operation provides precise voltage regulation and sine wave output. It isolates connected equipment from most power problems, including blackouts, brownouts, overvoltages, transient voltages surges, electromagnetic (EMI/RFI) line noise, harmonic distortion, electrical impulses and frequency variations.
Zero transfer time to battery prevents malfunctions and reboots of sensitive equipment potentially caused by the transition from line power to battery-derived power during outages.
Fault-tolerant automatic bypass maintains utility output and avoids downtime during a variety of fault and overload conditions.

Flexible Management Options

There are several ways to manage this UPS system:
Use the multifunction LED/LCD panel for comprehensive local management.
Use the USB port with your computer's built-in power management features.
Use the USB or serial port with your computer and Tripp Lite's PowerAlert® software. PowerAlert provides enhanced features like automatic file saves, event notification, logging, advanced device control and an SNMP agent that supports centralized management. Select UPS models include a convenient CD-ROM, or you can download the latest version of PowerAlert for free at Tripp Lite's website.
Install an optional network card to enable standalone network management via SNMP, Web, SSH or telnet. The network card has an Ethernet port and embedded interface, allowing you to access advanced monitoring, control and notification features without directly connecting the UPS system to a computer. The network card also supports connecting one or more optional sensors for remote temperature, humidity and contact closure monitoring. (Available network cards and sensors include TLNETCARD with TLNETEM sensor; WEBCARDLX with E2MT, E2MTDO, E2MTDI and E2MTHDI sensors; and SNMPWEBCARD with ENVIROSENSE sensor. Refer to each model for specific features.)

Multifunction LCD/LED Control Panel

The convenient LCD/LED control panel provides easy access to detailed UPS settings and information. The illuminated LCD screen displays a variety of helpful data, including input/output voltage, input/output frequency, load level and battery level. An LED block diagram supplements the LCD screen by indicating the UPS operating mode and power conditions. The control panel also allows you to change the UPS system's operating mode and other settings. The control panel provides more information and greater control than comparable models, allowing you to diagnose and respond to power problems at the rack before they cause downtime.

Eco-Friendly Design

Economy Mode: This UPS system provides user-selectable economy mode operation to increase efficiency and cut operating costs. In economy mode, the UPS system suspends double conversion and operates with increased efficiency as long as input power quality is satisfactory. If input power quality becomes unsatisfactory, the UPS system immediately resumes double conversion until power quality returns to normal.
User-Replaceable Battery: This UPS system has a user-replaceable, recyclable battery, allowing it to remain in service instead of going to a landfill.
RoHS Compliance: This UPS system complies with the RoHS (Restriction of Hazardous Substances) Directive, limiting the use of hazardous substances in manufacturing.

Dependable Service from an Industry Leader

Service and Support

2-Year Product Warranty: If this UPS system (including the internal battery) proves defective in material or workmanship within that period, Tripp Lite will repair or replace it at no charge.
$250,000 Insurance: Tripp Lite will repair or replace connected equipment damaged by surges – even lightning strikes!
Free Tech Support: Chicago-based, in-house tech specialists are available by phone, email and chat.

Industry Leader

Over 95 Years: Founded in 1922, Tripp Lite has a long-established and proven track record of providing reliable products and responsive customer service.
Trusted Name: From the smallest office to the largest data center, customers worldwide trust Tripp Lite to power, protect, manage and connect valuable IT equipment.
Third-Party Safety Testing and ISO 9001 Certification

Key Specifications

Model: SU5000RT4UHV
Load Capacity: 5 kVA (4.5 kW)
Power Factor: 0.9
Nominal AC Input: 200V; 208V; 240V (50/60 Hz)
Nominal AC Output: 200V; 208V; 240V (50/60 Hz)
Output Voltage Regulation (Line Mode): +/- 2%
AC Outlets: 2 x L6-20R; 2 x L6-30R
Output Waveform (AC Mode): Pure Sine Wave
Output Waveform (Battery Mode): Pure Sine Wave
Input Cord: 10 ft. (3 m) Cord with L6-30P Plug
Half-Load Runtime (Included Batteries): 11 min. (2250 W Load)
User-Replaceable Battery: Yes (RBC5-192)
Expandable Battery Runtime: Yes (Requires Optional External Battery Pack)
Compatible External Battery Packs: BP192V1037C-1PH; BP192V12-3U; BP192V1407C-1PH; BP192V557C-1PH; BP192V787C-1PH; BP192V5RT2U (limit 1)
Communications: HID-Compliant USB Port, DB9 Serial Port; Contact Closure; Network Card Slot; EPO
Primary Form Factor: 4U Rack. Supports 4-post rack installation with included kit. (Add 2POSTRMKITHD for 2-post rack installation.)
Dimensions: 6.9 x 17.5 x 20.7 in. (17.5 x 44.5 x 52.5 cm)
Unit Weight: 113.6 lb. (51.5 kg)
Standards: UL 1778 (USA); CSA (Canada); FCC (EMI); RoHS
Product Warranty (Worldwide): 2-Year Limited Warranty
Connected Equipment Insurance (U.S., Canada and Puerto Rico): $250,000
What's Included: UPS, 4-Post Rack Installation Kit, USB/Serial/EPO Cabling, Manual

Tripp Lite has a policy of continuous improvement. Specifications are subject to change without notice. Actual products may differ slightly from photos. Tripp Lite uses primary and third-party agencies to test its products for compliance with standards. Runtime varies with load, battery condition and other factors. Go to Tripp Lite's website for more information, including complete warranty terms and conditions.

Documents

The Tripp Lite SU5000RT4UHV 5kVA on-line, double-conversion UPS system offers complete power protection for critical server, network and telecommunications equipment in a single 4U rack/tower compatible housing. Full-time active power conditioning provides clean, continuous dual-conversion AC output free of voltage fluctuations, power interruptions and line noise. Fault-tolerant auto-bypass prevents unexpected service interruptions during UPS overload or internal fault conditions. Single all-in-one rack / tower housing installs in only 4 rack spaces (4U) with a maximum installed depth of only 20.7 inch. It maintains full-time sine wave output within 2 per cent of selectable 200/208/220/230/240 Volt nominal during brownouts as low 100 Volt and overvoltages as high as 300 Volt. Expandable runtime is supported with optional BP192V12-3U external battery packs. Battery independent restart ensures automatic UPS power-up without user interaction after lengthy power outages, even when batteries are expired and require replacement. Double-conversion operation converts raw input from AC to DC, and then resynthesizes output power back to perfect sine wave AC with enhanced protection from harmonic distortion, fast electrical impulses and other hard-to-solve power problems not addressed by other UPS types.

Tech Specs

General

Device Type

UPS - external

Height (Rack Units)

Color

Attractive black

Power Device

UPS Technology

On-line

Input Voltage

AC 200/208/220/230/240 V

Frequency Provided

50/60 Hz

Frequency Required

50/60 Hz

Input Connectors

1 x power NEMA L6-30

Power Output Connectors Details

2 x power NEMA L6-20
2 x power NEMA L6-30

Output Voltage

AC 200/208/220/230/240 V ± 2% - 50/60 Hz

Power Capacity

4.5 kW / 5000 VA

Output Waveform

Sinewave

Surge Suppression

Yes

Surge Response Time

0 ns

Circuit Protection

Circuit breaker

Battery

Type

Expandable

Technology

Lead acid

Voltage Provided

192 V

Run Time (Up To)

3.5 min at full load

Recharge Time

6 hours

Networking

Remote Management Interface

RS-232, USB

Expansion / Connectivity

Interfaces

1 x management (RS-232) - 9 pin D-Sub (DB-9)
1 x management (USB) - 4 pin USB Type B
1 x EPO (emergency power off)

Expansion Slots

3 (total) / 3 (free) x expansion slot

Miscellaneous

Included Accessories

Power distribution unit (PDU)

Cables Included

Serial cable - external
USB cable - external
Power cable 10 ft

Rack Mounting Kit

Included

Equipment Protection Value

250000 US Dollars

Features

Audible alarm, emergency power off, LCD display, internal bypass, LED indicators, cold-start function

Compliant Standards

CSA, IEC 61000-4-5, UL 1778, RoHS, FCC Part 15 A

Software / System Requirements

Software Included

TrippLite PowerAlert

Environmental Parameters

Min Operating Temperature

32 °F

Max Operating Temperature

104 °F

Humidity Range Operating

5 - 90%

Sound Emission

65 dBA

Dimensions & Weight

Width

17.5 in

Depth

20.7 in

Height

6.9 in

Weight

113.76 lbs

Dimensions & Weight (Shipping)

Shipping Width

23.6 in

Shipping Depth

29.1 in

Shipping Height

12.7 in

Shipping Weight

151.9 lbs
