Be sure to read and follow the safety guidelines to protect your computer from potential damage and ensure your personal safety. For more information about safety guidelines, see the owner's manual at Dell.com/Support. Before you begin. Turn off the computer and disconnect all the attached peripherals.
Before proceeding ensure your computer is in service mode. To enter service mode, press and hold the key on the keyboard and then press the power button. Now the computer will boot up and the owner tag information is displayed on the screen.
Press any key to proceed. The computer will emit three short beeps and shut down, indicating it has entered the service mode. Loosen the captive screws holding the base cover in place. Using a plastic scribe, pry the base cover from the palm rest assembly. Starting at the top edge and working your way around to release it from all sides. Now lift the base cover from the palm rest assembly.
If your computer is unable to enter service mode, disconnect the battery cable from the system board. Identify the solid state drive 2230. Remove the two screws. Secure the SSD thermal plate. Lift the thermal plate. Lift the solid state drive holder and carefully release it from the hook to remove it. Slide and remove the solid state drive from the slot.
To reinstall the solid state drive. Slide the solid state drive into the M2 card slot. Slide the SSD holder over the hook and press it down. Align the thermal plate and firmly press to cover. Tighten the two screws to secure the thermal plate. If the battery cable was disconnected earlier, make sure to reconnect it to the system board.
Next, align the base cover with the palm rest assembly and gently place it into position. Tighten all required screws to secure the base cover in place to exit service mode. Connect the AC adapter and press the power button. Please note the system will only power on and exit service mode if the adapter is connected. For more information about your Dell system, visit Dell.com/Support.
