How to Replace the Hard Drive 3.5 on Optiplex 7070 SFF

This video will demonstrate replacement procedure of a Hard Drive 3.5 on Optiplex 7070 SFF.

To remove the hard drive, unlatch and remove the base cover. Unlatch and remove the front bezel. Identify and slide the tab to unlatch the hard drive assembly. Disconnect the cables and lift the assembly to remove it. Identify the hard drive, unlatch and remove it from the system.

To reinstall the hard drive, place it back in the system and relatch it. Reinsert the hard drive assembly and reconnect the cables. Relatch the assembly. Place the front bezel and base cover on the system.
