Dell Automation Platform: Resolving Connection Status issues due to Secure Remote Services

This issue occurs on Dell Automation Platform 1.0 - 1.2 for on-premises deployments.

Connection-status is utilized in the Dell Automation Platform Orchestrator in various sections, for example:

• Administration/Entitlement
• Spinning wheel or loading indicator appears in the License section of the Dell Private Cloud blueprint

When querying the API https://<orchestratorfqdn>/api/v2/eo-init/entitlements/connection-status an HTTP 500 error is reported.

{
    "http_status_code": 500,
    "messages": [
        {
            "message": "Failed to get entitlement connection status",
            "severity": "ERROR"
        }
    ]
}

This HTTP 500 error occurs due to an incomplete or misconfigured connection in Dell Secure Remote Services in the Dell Automation Platform Orchestrator.

Fix:

This issue is scheduled to be resolved in Dell Automation Platform 2.0.

Workaround:

To resolve this misconfiguration, a script is attached to this article which resets the Secure Remote Services within the Dell Automation Platform Orchestrator.

• Download the attached script, transfer it to the system that the Dell Automation Platform deployed on and extract the downloaded script.
• Change the execution bit of the file to be executable
  For example: chmod +x connectionstatus.sh
• Start an interactive root shell
  For example: sudo -s (supply the password when prompted)
• Run the script (you must supply the namespace that the orchestrator is deployed in)
  For example: ./connectionstatus.sh -n <namespace>

Once the script completes retry the Secure Remote Services connection if wanted and once complete, validate that the connection-status API returns an HTTP200 value (or at least not an HTTP500 error)

Example of the script being ran

dap-server:/home/mystic # ./connectionstatus.sh -n dapo
Cleaning up ese data on namespace dapo
Scaling down product svc pod on namespace dapo
deployment.apps/hzp-product-svc scaled
Pod hzp-product-svc-78d6d6cc5d-drmsz still exist, waiting...
Pod hzp-product-svc-78d6d6cc5d-drmsz still exist, waiting...
Pod hzp-product-svc-78d6d6cc5d-drmsz still exist, waiting...
Pod hzp-product-svc-78d6d6cc5d-drmsz still exist, waiting...
Pod hzp-product-svc-78d6d6cc5d-drmsz still exist, waiting...
Pod hzp-product-svc-78d6d6cc5d-drmsz still exist, waiting...
Scaling up product svc pod on namespace dapo
deployment.apps/hzp-product-svc scaled
Waiting for deployment "hzp-product-svc" rollout to finish: 0 of 1 updated replicas are available...
deployment "hzp-product-svc" successfully rolled out
All process completed successfully
