You cannot use onboard when a video card is in a slot.
The bios halts the system.
System halted! Attention: Unsupported Video Configuration Detected
Action is Required
This computer has an add-in graphics card, but the monitor is plugged into the integrated video connector. To attach the monitor cable to the add-in graphics card:
1. Shut down the computer 2. Plug the monitor cable into the add-in graphics card connector. This may require a video adapter or video adapter cable. (provided with the system) 3. Turn on the computer.
This message should not appear after completing these steps. For more information or help, please refer to the system documentation
The integrated video cannot be used when there is a card in the pci slot. The card must be physically removed from the computer to use the integrated video. That card used alone is probably not compatible with your old model computer. You don't have a PCi 3 slot or the required power supply.
from the manual--NOTE: The PCI Express x16 slot is disabled when a display is connected to the integrated video connector.
I thought cards were backwards compatible? Also, this card only draws 65W of power which should be within the 305W power supply. I could be wrong but I am trying to use the card over the integrated graphics. Thank you!
65w GPU card on 305w PSU should be fine. Mary is right about the integrated graphics. Integrated graphics can't be used at the same time as a GPU card. If card still isn't working, consider that the card may be defective. As long as you used the PCI-e x16 slot, technically, it should work.
You can learn more about Dell’s privacy statement regarding customer information here: https://dell.to/3p2YjEH
Please share your email address. In case this chat is disconnected, we will email you a ‘Resume Chat’ link to reinitiate this conversation.
9:19 AM
Please provide a email address to continue.
9:20 AM
<Private data removed from public view. DELL-Admin>
9:27 AM
Thank you. We have sent the ‘Resume Chat’ link to your email address. Please use this link if the chat ends abruptly or you want to reinitiate it.
Type or share a photo of the Service Tag or Express Service Code label so we can review your system configuration. For assistance in locating your system's Service Tag watch the following video: https://youtu.be/xxISMlXqyVQ
9:27 AM
I have a Dell Optiplex 780 mini-tower running Windows 10 64-bit and bios A15 updated it as well via a flash drive. I have once installed a 2GB GT 710 NVIDIA GPU(It was working fine till recently when I was cleaning up my PC), When I reassemble my PC and I attempt to boot up the computer I get an error. I can't even F12 or F2 pass this error no matter how many times I try. "Atention: Unsupported Configuration Detected Action is Required This computer has both a display port monitor attached and a card installed in the PCI-express slot 1. This configuration is not supported. Please disconnect the PCI-express card or disconnect the display port monitor." I have the VGA cable plugged into the 2GB GT 710 NVIDIA GPU and that's when the monitor gives me the error, the monitor stays black whenever it's plugged into the integrated graphics.
speedstep
9 Legend
•
47K Posts
0
July 27th, 2020 13:00
You cannot use onboard when a video card is in a slot.
The bios halts the system.
System halted!
Attention: Unsupported Video Configuration Detected
Action is Required
This computer has an add-in graphics card, but the monitor is plugged
into the integrated video connector.
To attach the monitor cable to the add-in graphics card:
1. Shut down the computer
2. Plug the monitor cable into the add-in graphics card connector.
This may require a video adapter or video adapter cable.
(provided with the system)
3. Turn on the computer.
This message should not appear after completing these steps.
For more information or help, please refer to the system documentation
Mary G
4 Operator
•
20.1K Posts
1
July 23rd, 2020 10:00
The integrated video cannot be used when there is a card in the pci slot. The card must be physically removed from the computer to use the integrated video. That card used alone is probably not compatible with your old model computer. You don't have a PCi 3 slot or the required power supply.
from the manual--NOTE: The PCI Express x16 slot is disabled when a display is connected to the
integrated video connector.
Mary G
4 Operator
•
20.1K Posts
0
July 23rd, 2020 10:00
see post below
donm4599x
2 Intern
•
478 Posts
0
July 23rd, 2020 15:00
As usual, you nailed it Mary. The only solution is to buy a new computer!
nowayjose425
1 Rookie
•
4 Posts
0
July 23rd, 2020 16:00
I thought cards were backwards compatible? Also, this card only draws 65W of power which should be within the 305W power supply. I could be wrong but I am trying to use the card over the integrated graphics. Thank you!
bradthetechnut
7 Technologist
•
9.3K Posts
1
July 23rd, 2020 18:00
65w GPU card on 305w PSU should be fine. Mary is right about the integrated graphics. Integrated graphics can't be used at the same time as a GPU card. If card still isn't working, consider that the card may be defective. As long as you used the PCI-e x16 slot, technically, it should work.
Sizo.P
1 Rookie
•
1 Message
0
June 12th, 2024 07:33
(edited)
bradthetechnut
7 Technologist
•
9.3K Posts
0
June 13th, 2024 02:48
@Sizo.P
Did you try removing the GT 710 and then try VGA on the integrated graphics?
If it's 5+ years old, try replacing the size 2032 CMOS battery. Bad batteries affect BIOS making for some bizarre problems.
