VxRail: Node Add Operation Failure "Error adding 3 host to the cluster. Monitorowanie kondycji jest wyłączone podczas wykonywania tego zadania"

Summary: Podczas dodawania węzłów do klastra operacja kończy się niepowodzeniem podczas budowania grupy dysków, ale zadanie jest nadal uruchomione w vSphere.

This article applies to This article does not apply to This article is not tied to any specific product. Not all product versions are identified in this article.
Check out other resources

Symptoms

Dodanie węzła kończy się niepowodzeniem w kroku "Budowanie grup dysków vSAN w klastrze" z wtyczki VxRail:


Zadanie utworzenia grupy dysków jest jednak kontynuowane w vCenter:


short.term.log:

2022-03-02-21:56:03 microservice.nano-service "Traceback (most recent call last):"
2022-03-02-21:56:03 microservice.nano-service "  File ""/home/app/common/atomic.py"", line 236, in execute"
2022-03-02-21:56:03 microservice.nano-service "    self._return = self.perform(*args, **kwargs)"
2022-03-02-21:56:03 microservice.nano-service "  File ""/home/app/hostvsandiskgroupscreate/host_vsan_diskgroups_create.py"", line 214, in perform"
2022-03-02-21:56:03 microservice.nano-service "    params=(self.host_name,))"
2022-03-02-21:56:03 microservice.nano-service "  File ""/home/app/common/atomic.py"", line 278, in raise_error"
2022-03-02-21:56:03 microservice.nano-service "    raise NanoException(code=code, params=params, message=message)"
2022-03-02-21:56:03 microservice.nano-service "common.nano_exception.NanoException: {""code"": ""E3100_Storage_4"", ""params"": [""esxi-01***""], ""message"": ""Failed to create multiplue disk group esxi-01***""}"
2022-03-02-21:56:03 microservice.nano-service ""
2022-03-02-21:56:03 microservice.nano-service "[common.atomic] 2022-03-02 21:56:03,516 DEBUG 9:Dummy-374 [atomic.py:19] trigger_event(): step_message: HostVsanDiskgroupsCreate Fail."
2022-03-02-21:56:03 microservice.nano-service "[dayone] 2022-03-02 21:56:03,516 ERROR 9:Dummy-374 [utils.py:203] wrapper(): Caught for log, will raise this exception again.Traceback (most recent call last):"
2022-03-02-21:56:03 microservice.nano-service "  File ""/home/app/hostvsandiskgroupscreate/host_vsan_diskgroups_create.py"", line 210, in perform"
2022-03-02-21:56:03 microservice.nano-service "    do_storage.sync_call_do(do_storage.build_call_do_service_task_url(url), body, method=""POST"")"
2022-03-02-21:56:03 microservice.nano-service "  File ""/home/app/common/utils.py"", line 198, in wrapper"
2022-03-02-21:56:03 microservice.nano-service "    rets = func(*args, **kargs)"
2022-03-02-21:56:03 microservice.nano-service "  File ""/home/app/common/do.py"", line 308, in sync_call_do"
2022-03-02-21:56:03 microservice.nano-service "    'task {} for {} {} failed with timeout.'.format(task_id, method, path))"
2022-03-02-21:56:03 microservice.nano-service "Exception: task b4076ad8-d9a6-4e10-a360-aed4460e1935 for POST /rest/vxm/internal/do/v1/storage/vsan/diskgroups/initialize failed with timeout."

Cause

Podstawowy problem z vSAN, taki jak wolne połączenie z serwerem KMS, może spowodować wydłużenie czasu zadania. Limit czasu narzędzia VxRail Manager zostanie przekroczony przed zakończeniem zadania.

Resolution

Rozwiązanie problemu:

  1. Poczekaj na zakończenie zadania tworzenia grupy dysków w vCenter.
  2. Zadanie ponowienia próby z wtyczki VxRail Manager powiodło się.

Affected Products

VxRail, VxRail Appliance Series, VxRail Software
Article Properties
Article Number: 000196967
Article Type: Solution
Last Modified: 04 Sept 2025
Version:  2
