Alienware Command Center Quick Guide

Summary: The Alienware Command Center is an exclusive software that has designed to control features of your Alienware Computer and some G Series Systems including AlienFX, Alien Touch, AlienSee more

This article may have been automatically translated. If you have any feedback regarding its quality, please let us know using the form at the bottom of this page.

Article Content


Symptoms

alienhead

Supported Systems:


  All Alienware and some G Series Systems


What is the Alienware Command Center?

The Alienware Command Center is an exclusive software that integrates into a single interface application that is designed to control features of your Alienware Computer. It comes preinstalled in your computer.

There is a Command Center version for every Alienware computer, and each version enables different features depending on your computer model.

To download the correct version for your computer browse to dell.com/support. For more information, see Dell Knowledge Base article Drivers and Downloads FAQs.


Command Center Features Matrix

System Command Center
Version
Alien
FX
Alien
FX 2.0
Alien
Fusion
Game
Library
Alien
Adrenaline
Alien
Touch
Alien
TactX
Thermal
Controls
OC
Controls
Alien
Sense
Area-51m R1/R2 5.2.91.0   Y Y Y       Y Y
Alienware m17 R1/R2/R3   Y Y Y       Y Y
Alienware m15 R1/R2/R3   Y Y Y       Y Y
Alienware 15 R4   Y Y Y       Y Y
Alienware 17 R5   Y Y Y       Y Y
Alienware Area-51 R4/R5   Y Y Y       Y Y
Alienware Area-51 Threadripper Edition R3/R6/R7   Y Y Y       Y Y
Alienware Aurora R8/R9/R11/ Ryzen Edition   Y Y Y       Y Y
Alienware Area-51 R2 4.8.25.0 Y   Y   Y     Y Y
Alienware 13 R3 4.8.23.0 Y   Y   Y
Alienware 15 R3 Y   Y   Y   Y
Alienware 17 R4 Y   Y   Y   Y   Y
Alienware Aurora R5/R6 Y   Y   Y     Y Y
Alienware Aurora R7 4.8.20.0 Y   Y   Y     Y Y
Alienware Alpha R2 4.6.16.0 Y   Y   Y
Alienware 13 R2 4.5.19.1 Y   Y   Y
Alienware 15 R2 Y   Y   Y   Y
Alienware 17 R3 Y   Y   Y   Y
Alienware X51 R3 4.5.18.0 Y   Y   Y
Alienware Alpha 4.0.56.0 Y   Y   Y
Alienware 13 4.0.54.0 Y   Y   Y
Alienware 15 Y   Y   Y   Y
Alienware 17 R2 Y   Y   Y   Y
Alienware X51 R2 4.0.51.0 Y   Y   Y
Alienware Aurora R4 3.6.5.0 Y   Y   Y     Y
Alienware 14 3.6.4.0 Y   Y   Y Y
Alienware 17 Y   Y   Y Y Y
Alienware 18 Y   Y   Y Y Y
Alienware Area 51 ALX 2.8.9.1 Y   Y
Alienware Area 51 2.8.9.0
Alienware Aurora
Alienware Aurora R2
Alienware Aurora R3
Alienware X51
Alienware M11x R3 2.8.8.0 Y   Y     Y
Alienware M14x R1/R2 Y   Y     Y
Alienware M17x R3/R4 Y   Y     Y
Alienware M18x R1/R2 Y   Y     Y Y
Alienware M11x R1/R2 2.5.54.0 Y   Y             Y
Alienware M15x Y   Y             Y
Alienware M17x R1/R2 Y   Y             Y
Alienware Aurora ALX Y   Y             Y
System Command Center
Version
Alien
FX
Alien
FX 2.0
Alien
Fusion
Game
Library
Alien
Adrenaline
Alien
Touch
Alien
TactX
Thermal
Controls
OC
Controls
Alien
Sense
Dell G3 15 3500 5.2.91.0   Y* Y Y       Y Y
Dell G3 15 3590     Y Y       Y Y
Dell G5 15 5500   Y* Y Y       Y Y
Dell G5 15 5590     Y Y       Y Y
Dell G5 5000   Y Y Y       Y Y
Dell G5 5090     Y Y       Y Y
Dell G5 SE 5505     Y Y       Y Y
Dell G7 15 7500   Y Y Y       Y Y
Dell G7 15 7590     Y Y       Y Y
Dell G7 17 7700   Y Y Y       Y Y
Dell G7 17 7790     Y Y       Y Y
Dell G3 3579
Dell G3 3779
Dell G5 15 5587
Dell G7 15 7588

NOTE: Systems must be configured with the optional RGB keyboard in order to support Alien FX 2.0. Systems that are configured with the standard backlit keyboard will not support AlienFX 2.0. Please see your invoice to confirm the type of keyboard in your computer.

More Information

Click each item to learn more about each feature in Alienware Command Center.

Install Alienware Command Center on another computer (Dell G-Series or non-Alienware computers).

Learn how to install the Alienware Command Center on another computer like Dell G-Series or any other non-Alienware computer.


Alienware: Reinstall Alienware Command Center

Learn how to properly reinstall your Alienware Command Center.


New Alienware Command Center 2018

Discover the new Alienware Command Center software, an all in one stop for all your gaming needs. Inside you can control fans, monitor heat, and create overclocking profiles.


Alienware Macro Keys and Alienware Command Center AlienFX

Learn how to browse the new Control Center application, configure macro keys, lights, and customizable presets. In this video, we will show case every screen for the mouse and keyboard.


AlienFX lets you choose from an array of color and transition effects across multiple distinct zones on your computer and Alienware devices.

AlienFX 2.0 is in the new Alienware Command Center (Version 5.0 and higher) and offers a brand new interface. Save new themes, assign them to your games and edit device settings with new AlienFX hardware and software featuring support for full RGB values and up to 16.8 million colors. Included is a new user interface to map and create new system-level effects so you can manage lighting and settings from the same controls. Select computers, and hardware also offer settings for individual or group keyboard key colors.

On Command Center versions below version 5.0 AlienFusion gives you access to your Alienware's power management controls so you can decide when you need maximum performance or when you can scale back for more everyday programs, increasing energy efficiency and extending battery life for laptops.

With the new Alienware Command Center (Version 5.0 and Higher) Fusion allows you to control the power settings, thermal controls, and audio settings, all in one place.

The easy-to-use interface links all your various computer settings with a gaming library, making it simple to access gaming information. No matter what the source, the command center gives you access to your games and the ability to fine-tune settings for each one. Create a unique game profile and it stays just how you want it, no matter where you launch.

SLN128904_en_US__3image(2703)

With AlienAdrenaline you will access to:

  • Game Mode: Create profiles for each of your games to change the computer lighting, open VoIP programs, launch monitoring programs and many other functions automatically when you launch your game.

  • Performance Monitoring: See real-time stats of your CPU, Memory, Video Card and WLAN and record them in the background to review your computer performance.

  • Alienware Graphics Amplifier (Selected Systems Only): On computers supporting the Alienware Graphics Amplifier, you can see connection status and also configure the behavior of the computer when disconnecting the Alienware Graphics Amplifier.

AlienTouch allows you to change the Touchpad settings on your Alienware Laptop Computer. Tapping, Sensitivity and Virtual Scrolling are the options available under AlienTouch.

Important: AlienTouch is only available on the following computers:

Alienware 18   Alienware 17 R1   Alienware 14   Alienware M17x (All)
Alienware M18x (All)   Alienware M14x (All)   Alienware M15x   Alienware M11x (All)

AlienTactX allows you to change the settings for the Macro keys*. The TactX window allows you to change color schemes for the Macro Keys and set the shortcut options.

Thermal Controls give you access to your Alienware's management thermal computer controls so you can monitor thermal status, adjust thermal control of computer fans, and change the status of active venting.

For computers supporting Alienware Command Center version 5.0 and higher you will find the thermal controls under the Fusion tab.

This feature is currently available only in the Alienware Area-51 R2, R3, R4, R5, R6, Aurora R5, R6, R7, Alienware 17 R4, R5, and 15 R3, R4 with the Intel Core i7-6820HK/i7-7820HK processor/i9-8950HK processor; it enables you to monitor CPU, DRAM, and the Overclocking Profile.

Aliensense is a face detection program that allows you to log in to your computer through face detection and setup other functions such as user switch and lock the computer when you are away.

Important: Aliensense is only available on the Alienware M17x R1, Alienware M15x, and Alienware M11x R1.

Cause

SLN316295_en_US__1I_aw_2016logo_mr_v1

  SLN316295_en_US__2iC_aw_twitter_mr_v1   SLN316295_en_US__3iC_aw_youtube_mr_v1   SLN316295_en_US__4iC_aw_facebook_mr_v1   SLN316295_en_US__5iC_aw_alienhead_mr_v1

Resolution


Out of Warranty support Out of warranty? No problem. Browse to the Dell.com/support website and enter your Dell Service Tag and view our offers.

NOTE: Offers are only available for US, Canada, UK, France, Germany, China, and Japan personal computer customers. Server and Storage not applicable.
