Dell and AMD Threadripper a Powerful Combination

AMD Ryzen™ Threadripper™ PRO
Bring exceptional performance to any configuration.

Design. Build. Accelerate. On the Ultimate Workstation Processor.


The simulation results are due by end of day. The design review moved up two weeks. The shot needs to be rendered by one o’clock. When your business needs to get the job done, moving the deadline isn’t an option. Artists, architects, and engineers require a highly expandable workstation platform that can deliver unmatched reliable full spectrum performance with enterprise class security features, manageability and unrivaled expandability. AMD Ryzen™ Threadripper™ PRO processors enable demanding professionals to get more done in less time. 2,3,4

Architecture, Engineering, and Construction

Architecture, Engineering, and Construction

ACHIEVE YOUR ASPIRATIONS – The portfolio of AMD Threadripper PRO processors offer the best of both worlds, with high click speeds to help accelerate lightly 3D design and modeling and up to 96 cores for multithreaded rendering and reality capture.



High CPU clock speeds for fast 3D designs.

Design and Manufacturing

Design and Manufacturing



ACCELERATE YOUR VISION– The portfolio of AMD Threadripper PRO processors offer the best of both worlds with high frequency cores to help accelerate 3D modeling and design performance. Along with exceptional memory
capacity and memory channels to take on the most complex projects.

Create 3D models seamlessly and effectively with high CPU clock speed workstation processors.

Media and Entertainment

Media and Entertainment



SPEED UP WORKFLOWS – The portfolio of AMD Threadripper PRO processors offer capability and platform expandability allowing you to create and render simultaneously, without sacrificing performance.



Reduce render times with leadership core counts to accelerate multi-threaded tasks.

Software and Sciences

Software and Sciences



ACCELERATE YOUR ANALYSIS– The portfolio of AMD Threadripper PRO processors with up to 96 cores can help dramatically reduce compile times. This is why over 30 leading game developers trust Threadripper PRO to iterate their code faster and bring more robust applications to market in less time.

Level up your designs with leadership core counts.

AMD Ryzen Threadripper PRO Processors

AMD Threadripper 7875
AMD Threadripper 7875.

The portfolio of AMD Threadripper PRO high-performance processors are designed for the most demanding professional workflows. Building upon the extensively-tested capabilities of the 5000 WX-Series, the 7000 WX-Series further elevates your workstation experience.

AMD Ryzen™ Threadripper™ PRO 5000 WX-Series Processors

AMD PRO Technologies

AMD PRO technologies deliver a complete set of features that are essential for the modern business. ITDMs can take advantage of its cutting-edge security features, robust manageability tools, and enterprise-grade stability and reliability. AMD Ryzen PRO processors with AMD PRO technologies provide you the confidence that your PC will perform quickly and reliably, for the ultimate business experience.

Which AMD Threadripper PRO Platform is right for your needs?

7865 Tower 7875 Tower
Platform AMD Zen3 Chagall AMD Zen 4 Storm Peak
CPU Ryzen Threadripper Pro 280W TDP up to 64 cores Ryzen Threadripper Pro 350W TDP up to 96 cores
PCH WRX80 Pro 695
Memory 8x channels of DDR4 @3200MHz RDIMM ECC
Total capacity of 8 DIMMs up to 1TB
8x channels of DDR5 @4800MHz RDIMM ECC
Total capacity 8 DIMMs up to 2TB
PCIe Slots 5x PCIe slots, Gen4
2x x16 (mechanical and electrical), 3x x8 open-ended (mechanical and electrical)
6x PCIe slots, Gen 5 and Gen 4
1x x16 Gen5, 1x x8 Gen5 open-ended, 1x x16 Gen4, 2x x8 Gen4 open-ended
1x x8 Gen4 open-ended (8x mechanical, 4x electrical)
Graphic Card 2x Double wide graphics cards in slot 1, slot 4 2x Double wide graphics cards in slot 2, slot 5
Storage Drive Support 2x internal M.2NVMe motherboard slots (2230 or 2280)
2x internal 2.5” or 3.5” SATA drive bays
2x external Flexbays supporting:
· Up to 2x storage drives (NVMe or SATA) + optional slim ODD
· 1x storage drive (NVMe or SATA) + optional Half-Height ODD
1x UltraSpeed Duo (2x NVMe) or UltraSpeed Quad (4x NVMe) PCIe Add-In Card
2x internal M.2NVMe motherboard slots (2230 or 2280)
2x internal 2.5” or 3.5” SATA / SAS drive bays
2x external Flexbays supporting:
· Up to 2x storage drives (NVMe or SATA or SAS) + optional slim ODD
· 1x storage drive (NVMe or SATA) + optional Half-Height ODD (No HH ODD w/SAS)
1x UltraSpeed Duo (2x NVMe) or UltraSpeed Quad (4x NVMe) PCIe Add-In Card
Storage Controller Integrated AMD RAIDXpert supporting SATA/NVMe RAID 0, 1, 5, 10 Integrated AMD RAIDXpert supporting SATA/NVMe RAID 0, 1, 5, 10
Broadcom MegaRAID 9540-8i supporting software SATA/SAS RAID 0, 1, 10
Broadcom MegaRAID 9660-16i supporting hardware SATA/SAS RAID 0, 1, 5, 10
Front IO Power switch with LED; HDD activity LED; 1x Universal Audio Jack; SD6.0 card reader; 2x USB3.2 Gen1 (5Gb/s) Type-A; 2x USB 3.2 Gen2 (10Gb/s) Type-C (one with power share) Power switch with LED; HDD activity LED; 1x Universal Audio Jack; SD6.0 card reader; 2x USB3.2 Gen1 (5Gb/s) Type-A; 2x USB 3.2 Gen2 (10Gb/s) Type-C (one with power share)
Rear IO Audio Line out; 1x Serial / 2x PS2 (optional); 1x RJ45 (1Gb); 1x RJ45 (10Gb); 3x USB3.2 Gen2 (10Gb/s) Type-C; 3x USB 3.2 Gen1 (5Gb/s) Type-A Audio Line out; 1x Serial / 2x PS2 (optional); 1x RJ45 (1Gb); 1x RJ45 (10Gb); 3x USB3.2 Gen2 (10Gb/s) Type-C; 3x USB 3.2 Gen1 (5Gb/s) Type-A
PSU Internal 1000W / 1350W PSU Internal 1000W / 1350W PSU
Systems Management AMD Advanced Management with DASH AMD Advanced Management with DASH
Security TPM 2.0, Dell Data Protection Suite, AMD Pro Security, Intrusion Switch, BIOS PW, Kensington Slot, Padlock Ring, Optional Locking Storage Sled, Optional SED storage TPM 2.0, Dell Data Protection Suite, AMD Pro Security, Intrusion Switch, BIOS PW, Kensington Slot, Padlock Ring, Optional Locking Storage Sled, Optional SED storage
Dimensions Height: 417.9mm Width: 176.5mm Depth: 452.1mm Height: 446.6 mm Width: 176.5mm Depth: 487.5mm

Precision Configuration

Precision 7865 Configuration

Power your productivity

Configure your Dell Precision Desktop Workstation featuring AMD Ryzen Threadripper PRO processors.

If you need assistance please reach out to your Dell sales representative.

AMD Radeon PRO Graphics

AMD Radeon™ PRO Graphics


Premium Design. Premium Features.

Explore the next generation of professional graphics – built to perform and inspire your creative vision.

Create

Create

Accelerate Your Performance

From industrial product design to automotive and aerospace, get performance and speed for your design and manufacturing workflows.

Visualize

Visualize

Manage Complex Projects

Take on demanding, large photorealistic architectural, engineering and construction environments in real time while completing other tasks simultaneously.

Inspire

Inspire

Create Without Restraints

Load enormous 3D scenes, compute real-time effects, take advantage of AI enabled features and encode/decode workloads at the same time.
