This video will guide you in moving a volume in your EqualLogic group From one storage pool to another. To use this video, you will need the following: An EqualLogic group with at least two storage pools running version 6.0.7 or later. A Java-enabled browser supported by your current firmware.
Check the firmware release notes if you encounter issues. The IPV4 address for the group. Credentials for a group administration account on this group, Such as "grpadmin." The volume name of the volume you wish to move. Open a web browser with the group IPV4 address. Log in using the administration account credentials.
The main group information screen will appear. Choose Volumes in the Administration portion of the Activities section. Choose Move Volume in the Volume portion of the Activities section. The Move Volume dialogue will appear. Under the Destination Pool, the Available Storage Pools will be displayed With the volume's current pool selected.
Choose the new destination storage pool. The Destination Pool Space table will show the new pool space. If all entries in the Destination Pool Space table show green, There is enough available space to move the volume. If any table entries are marked red, you will need to select a different pool. Choose the Ok button when complete. Your volume will now be moved to the destination pool.
Thank you for watching.
