Manufacturer part SU6000RT4UTF | Dell part A3803681 | Order Code a3803681 | TrippLite
SU6000RT4UTF SmartOnline® Hot-Swappable Double-Conversion Rack/Tower Sine Wave UPS with Bypass Switch, Expandable Runtime, Network Slot, Low-Voltage Transformer and LCD
POWER PROTECTION AND EXPANDABLE BATTERY BACKUP
for servers and network hardware
This on-line, double-conversion UPS system protects critical network systems from damage, downtime and data loss.
for servers and network hardware
This on-line, double-conversion UPS system protects critical network systems from damage, downtime and data loss.
- True on-line, double-conversion operation delivers pure sine wave output, precise voltage regulation and isolation from power problems.
- Expandable battery backup supports critical systems during outages.
- Bypass switch allows UPS power module to be removed for maintenance, repair or replacement without requiring connected equipment downtime.
- LCD/LED control panel displays power conditions and permits easy access to settings.
- Network card slot supports optional remote access and network management.
- USB and DB9 serial ports connect to computers for power management.
- High-voltage output and low-voltage transfomer provide wide-ranging equipment compatibility.
- 2-year warranty and $250,000 insurance reflect commitment to reliability.
.png)
.jpg)
.png)
.png)
.png)
.png)
.png)
.png)
.png)
4:06Why is this UPS a Good Investment?
The success of your organization depends on critical information systems like servers and network hardware. If your critical systems don't have reliable power, employees can't work, communications go down, automated systems malfunction and productivity grinds to a halt. It would be nice if utility power was always reliable, but it isn't. Between severe weather, the aging electrical grid and hazards lurking inside your own walls, your servers and network hardware are under attack from power problems. Even a brief loss of power or a momentary surge can damage your equipment, corrupt your data, bring down your network and hurt your bottom line.The potential costs of downtime are alarming. Surveyed averages range from $1,167 per minute for mid-size businesses (IDC) to $7,908 per minute for larger operations (Ponemon Institute). For a tiny fraction of these costs, you can prevent damage, downtime and data loss by installing this SmartOnline UPS system. True on-line double conversion is the highest level of power protection available. It provides precise voltage regulation, delivers continuous sine wave output and isolates equipment from power problems. This UPS system also has a high power factor, allowing you to connect a heavier load without overloading the UPS.
.png)
Common Applications
Protect Mission-Critical Servers and Network HardwareApplication Servers, Storage Servers, Database Servers, File Servers, Virtualization Servers, Proxy Servers, Web Servers, Cloud Platform Servers, Media Servers, VoIP Servers, Converged Infrastructure, Network Switches, PoE Switches, Firewalls, Network Appliances, Bridges, Gateways, Routers
Protect Equipment with Active PFC Power Supplies
Active PFC power supplies found in many devices require sine wave power.
.png)
Expandable Battery Backup
- Half-Load Runtime: This UPS system will support a 50% load (2700W) for up to 8.5 minutes using the included batteries.
- Extended Runtime: This UPS system allows you to connect one or more optional external battery packs to provide additional backup runtime. Some external battery packs can also be daisy-chained, allowing you to scale runtime to match almost any application requirement.
- Hot-Swappable Batteries: You can add or replace batteries without turning off the UPS system and disrupting the operation of connected equipment.
.png)
On-Line, Double-Conversion Operation
This UPS system provides the highest level of power protection available:- Continuous on-line, double-conversion operation provides precise voltage regulation and sine wave output. It isolates connected equipment from most power problems, including blackouts, brownouts, overvoltages, transient voltage surges, electromagnetic (EMI/RFI) line noise, harmonic distortion, electrical impulses and frequency variations.
- Zero transfer time to battery prevents malfunctions and reboots of sensitive equipment potentially caused by the transition from line power to battery-derived power during outages.
- Fault-tolerant automatic bypass maintains utility output and avoids downtime during a variety of fault and overload conditions.
.png)
Hot-Swappable UPS with Bypass Switch
All SmartOnline UPS systems have hot-swappable batteries and an automatic internal bypass that delivers power directly to connected equipment in the case of an internal fault or severe overload. These features support the continuous availability of critical systems like servers and network hardware connected to the UPS.This UPS system also includes a detachable PDU with bypass switch to provide even higher system availability. When the switch is set to "bypass," you can completely remove the UPS power module for maintenance, repair or replacement without requiring downtime. The detachable PDU remains connected to the AC input power source and continues to supply power to connected equipment.
.png)
Flexible Management Options
There are several ways to manage this UPS system:- Use the multifunction LCD screen for comprehensive local management.
- Use the USB port with your computer's built-in power management features.
- Use the USB or serial port with your computer and Tripp Lite's PowerAlert® software. PowerAlert provides enhanced features like automatic file saves, event notification, logging, advanced device control and an SNMP agent that supports centralized management. Select UPS models include a convenient CD-ROM, or you can download the latest version of PowerAlert for free at Tripp Lite's website.
- Install an optional network card to enable standalone network management via SNMP, Web, SSH or telnet. The network card has an Ethernet port and embedded interface, allowing you to access advanced monitoring, control and notification features without directly connecting the UPS system to a computer. The network card also supports connecting one or more optional sensors for remote temperature, humidity and contact closure monitoring. (Available network cards and sensors include TLNETCARD with TLNETEM sensor; WEBCARDLX with E2MT, E2MTDO, E2MTDI and E2MTHDI sensors; and SNMPWEBCARD with ENVIROSENSE sensor. Refer to each model for specific features.)
.png)
Multifunction LCD/LED Control Panel
The convenient LCD/LED control panel provides easy access to detailed UPS settings and information. The illuminated LCD screen displays a variety of helpful data, including input/output voltage, input/output frequency, load level and battery level. An LED block diagram supplements the LCD screen by indicating the UPS operating mode and power conditions. The control panel also allows you to change the UPS system's operating mode and other settings. The control panel provides more information and greater control than comparable models, allowing you to diagnose and respond to power problems at the rack before they cause downtime..png)
Eco-Friendly Design
- Economy Mode: This UPS system provides user-selectable economy mode operation to increase efficiency and cut operating costs. In economy mode, the UPS system suspends double conversion and operates with increased efficiency as long as input power quality is satisfactory. If input power quality becomes unsatisfactory, the UPS system immediately resumes double conversion until power quality returns to normal.
- User-Replaceable Battery: This UPS system has a user-replaceable, recyclable battery, allowing it to remain in service instead of going to a landfill.
- RoHS Compliance: This UPS system complies with the RoHS (Restriction of Hazardous Substances) Directive, limiting the use of hazardous substances in manufacturing.
.png)
Dependable Service from an Industry Leader
Service and Support- 2-Year Product Warranty: If this UPS system (including the internal battery) proves defective in material or workmanship within that period, Tripp Lite will repair or replace it at no charge.
- $250,000 Insurance: Tripp Lite will repair or replace connected equipment damaged by surges – even lightning strikes!
- Free Tech Support: Chicago-based, in-house tech specialists are available by phone, email and chat.
- Over 95 Years: Founded in 1922, Tripp Lite has a long-established and proven track record of providing reliable products and responsive customer service.
- Trusted Name: From the smallest office to the largest data center, customers worldwide trust Tripp Lite to power, protect, manage and connect valuable IT equipment.
- Third-Party Safety Testing and ISO 9001 Certification
.png)
Key Specifications
Model: SU6000RT4UTFLoad Capacity: 6 kVA (5.4 kW)
Power Factor: 0.9
Nominal AC Input: 208V; 240V (60 Hz)
Nominal AC Output: 120V; 208V; 240V (60 Hz)
Output Voltage Regulation (Line Mode): +/- 2%
AC Outlets: 4 x 5-15R; 8 x 5-15/20R; 2 x L6-20R; 2 x L6-30R
Output Waveform (AC Mode): Pure Sine Wave
Output Waveform (Battery Mode): Pure Sine Wave
Input Cord: 10 ft. (3 m) Cord with L6-30P Plug
Half-Load Runtime (Included Batteries): 8.5 min. (2700W Load)
User-Replaceable Battery: Yes (RBC5-192)
Expandable Battery Runtime: Yes (Requires Optional External Battery Pack)
Compatible External Battery Packs: BP192V12-3U; BP192V557C-1PH; BP192V787C-1PH; BP192V1037C-1PH; BP192V1407C-1PH; BP192V5RT2U (Limit 1)
Communications: USB Port (HID-Compliant); Serial Port (DB9); Network Card Slot; EPO
Primary Form Factor: 6U Rack (Supports 4-post rack installation with included kit. Add 2 x 2POSTRMKITHD for 2-post rack installation. Add 2-9USTAND for tower installation.)
Power Module Dimensions: 6.85 x 17.5 x 20.7 in. (17.4 x 44.5 x 52.6 cm)
Power Module Weight: 116.2 lb. (52.7 kg)
Transformer Dimensions: 3.5 x 17.5 x 21.8 in. (8.9 x 44.5 x 55.4 cm)
Transformer Weight: 72.6 lb. (32.9 kg)
Standards: UL 1778 (USA); CSA (Canada); FCC A (EMI); RoHS
Product Warranty (Worldwide): 2-Year Limited Warranty
Connected Equipment Insurance (U.S., Canada and Puerto Rico): $250,000
What's Included: UPS, Low-Voltage Transformer, 4-Post Rack Installation Kit, USB/Serial/EPO Cabling, PowerAlert Software, Manual
Tripp Lite has a policy of continuous improvement. Specifications are subject to change without notice. Actual products may differ slightly from photos. Tripp Lite uses primary and third-party agencies to test its products for compliance with standards. Runtime varies with load, battery condition and other factors. Go to Tripp Lite's website for more information, including complete warranty terms and conditions.
.jpg)
Tripp Lite EZ-series SU6000RT4UTF 6000VA / 6kVA / 5400 watt on-line, double-conversion UPS system offers complete power protection for critical server, network and telecommunications equipment in a 6U rack/tower compatible configuration. Full-time active power conditioning provides clean, continuous dual-conversion AC output free of voltage fluctuations, power interruptions and line noise. Fault-tolerant auto-bypass prevents unexpected service interruptions during UPS overload or internal fault conditions. Detachable back panel PDU with manual bypass switch supports hot-swappable UPS power module replacement with no interruption to connected equipment. 4U UPS power module and included 2U low-voltage transformer install in only 6 rack spaces total (6U) with a maximum installed depth of only 21.8 in. / 55.3 cm. Maintains full-time sine wave output within 2% of selectable 208/240V and 120V nominal during brownouts as low 100V and overvoltages as high as 300V. Expandable runtime is supported with optional BP192V12-3U external battery packs. Battery independent restart ensures automatic UPS power-up without user interaction after lengthy power outages, even when batteries are expired and require replacement. Double-conversion operation converts raw input from AC to DC, then resynthesizes output power back to perfect sine wave AC with enhanced protection from harmonic distortion, fast electrical impulses and other hard-to-solve power problems not addressed by other UPS types. Highly efficient operation in optional economy mode significantly reduces BTU heat output and operating energy costs. Network-grade AC surge and noise suppression. Supports detailed monitoring of equipment load levels, self-test data and utility power conditions via built-in RS-232 and USB interfaces. Optional SNMP/Web and contact-closure communications card accessories available. HID-compliant USB interface enables integration with built-in power management and auto shutdown features of Windows and Mac OS X. Included PowerAlert monitoring software offers detailed site power and UPS updates with support for safe auto-shutdown of connected systems as UPS batteries become depleted. Included software packages include PowerAlert Local, PowerAlert Network Shutdown Agent and PowerAlert Network Management System for complete support for a wide variety of application types. Supports Emergency Power Off (EPO) via built-in interface. Front panel LEDs and LCD readout with scroll controls support front-panel visual monitoring of all major UPS for a variety of control options to support advanced UPS settings and configurations. LED / LCD display panel rotates for viewing in rackmount or tower configurations. L6-30P input plug. UPS supported outlets include two L6-30R, two L6-20R, 8 5-15/20R and 4 5-15R outlets. External battery packs are field replaceable and hot swappable.
Tech Specs
General
Device Type
UPS - externalBattery Enclosure Type
InternalHeight (Rack Units)
6URack Size
19"Power Device
UPS Technology
On-lineInput Voltage
AC 208/240 VFrequency Required
50/60 HzInput Connectors
1 x power NEMA L6-30Power Output Connectors Details
- 4 x power NEMA 5-15 (UPS and surge)
- 8 x power NEMA 5-15/20 (UPS and surge)
- 2 x power NEMA L6-20 (UPS and surge)
- 2 x power NEMA L6-30
Output Voltage
AC 120/208/240 V ± 2%Max Electric Current
31.9 APower Capacity
5.4 kW / 6000 VAOutput Waveform
SinewaveSurge Suppression
YesSurge Response Time
0 msCircuit Protection
Circuit breakerBattery
Voltage Provided
192 VRun Time (Up To)
2 min at full loadNetworking
Remote Management Interface
RS-232, USBExpansion / Connectivity
Interfaces
- 1 x management (USB)
- 1 x management (RS-232) - 9 pin D-Sub (DB-9)
- 1 x EPO (emergency power off)
Miscellaneous
Cables Included
- Power cable - external - 10 ft
- USB cable - external
- Serial cable - external
Rack Mounting Kit
IncludedEquipment Protection Value
250000 US DollarsFeatures
Hot-swappable, audible alarm, LED indicators, overvoltage protection, built-in bypass switch, undervoltage protection, cold-start function, cooling fanCompliant Standards
CSA, IEC 61000-4-5, UL 1778, RoHS, FCC Part 15 ASoftware / System Requirements
Software Included
TrippLite PowerAlertManufacturer Warranty
Service & Support
Limited warranty - 2 yearsEnvironmental Parameters
Min Operating Temperature
32 °FMax Operating Temperature
104 °FHumidity Range Operating
0 - 95%Sound Emission
60 dBADimensions & Weight
Width
17.5 inDepth
20.7 inHeight
6.9 inWeight
116.4 lbsDimensions & Weight (Shipping)
Shipping Width
25 inShipping Depth
30 inShipping Height
22.5 inShipping Weight
293.21 lbs
